select dmgeo.ST_POINTFromText('POINT (104.651271 28.718874)' , 4490)

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20

<dependency>
    <groupId>org.locationtech.jts</groupId>
    <artifactId>jts-core</artifactId>
    <version>1.20.0<ersion>
</dependency>
<!-- https://mvnrepository.com/artifact/org.geotools/gt-geojson-core -->
<dependency>
    <groupId>org.geotools</groupId>
    <artifactId>gt-geojson-core</artifactId>
    <version>27.0<ersion>
</dependency>

-- 仓库配置
<repositories>
    <repository>
        <id>osgeo</id>
        <name>OSGeo Release Repository</name>
        <url>https://repo.osgeo.org/repository/geotools-releases/</url>
    </repository>
</repositories>

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21

@Slf4j
@Configuration
public class JsonConfig {
    /**
     * 创建Jackson对象映射器
     *
     * @param builder Jackson对象映射器构建器
     * @return 增强后的ObjectMapper
     */
    @Bean
    @Primary
    public ObjectMapper getJacksonObjectMapper(Jackson2ObjectMapperBuilder builder) {
        ObjectMapper objectMapper = builder.createXmlMapper(false).build();
        objectMapper.registerModule(new JtsModule(11));
        //反序列化的时候如果多了其他属性,不抛出异常
        objectMapper.configure(DeserializationFeature.FAIL_ON_UNKNOWN_PROPERTIES, false);
        //日期格式处理
        objectMapper.setDateFormat(new SimpleDateFormat("yyyy-MM-dd HH:mm:ss"));
        return objectMapper;
    }
}

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89

import cjw.nic.niceasy.frame.common.util.SpringContextUtils;
import dm.jdbc.driver.DmdbBlob;
import dm.jdbc.driver.DmdbConnection;
import lombok.SneakyThrows;
import lombok.extern.slf4j.Slf4j;
import org.apache.ibatis.type.BaseTypeHandler;
import org.apache.ibatis.type.JdbcType;
import org.apache.ibatis.type.MappedJdbcTypes;
import org.apache.ibatis.type.MappedTypes;
import org.locationtech.jts.geom.Geometry;
import org.locationtech.jts.io.ByteOrderValues;
import org.locationtech.jts.io.WKBReader;
import org.locationtech.jts.io.WKBWriter;

import javax.sql.DataSource;
import java.sql.*;


/**
 * geometry 类型处理程序
 *
 * @author guoyingdong
 * @date 2025/05/13
 */
@MappedTypes({Geometry.class})
@MappedJdbcTypes({JdbcType.STRUCT})
@Slf4j
public class GeometryTypeHandler extends BaseTypeHandler<Geometry> {

    private static DmdbConnection connection = null;

    private static DmdbConnection getConnection() throws SQLException {
        synchronized (GeometryTypeHandler.class) {
            if (connection == null) {
                DataSource dataSource = SpringContextUtils.getApplicationContext().getBean(DataSource.class);
                connection = dataSource.getConnection().unwrap(DmdbConnection.class);
            }
        }
        return connection;
    }

    @Override
    public void setNonNullParameter(PreparedStatement preparedStatement, int i, Geometry geom, JdbcType jdbcType) throws SQLException {
        // Geometry转WKB
        byte[] bytes = new WKBWriter(2, ByteOrderValues.LITTLE_ENDIAN, false).write(geom);

        Object[] attrs = new Object[3];
        attrs[0] = 4490;
        DmdbConnection connection = getConnection();
        attrs[1] = DmdbBlob.newInstanceOfLocal(bytes, connection);
        attrs[2] = 6;
        //通过指定空间数据类型名称和结构体成员创建java.sql.Struct类型对象
        Struct struct = connection.createStruct("ST_GEOMETRY", attrs);
        preparedStatement.setObject(i, struct);
    }

    @SneakyThrows
    @Override
    public Geometry getNullableResult(ResultSet resultSet, String s) throws SQLException {
        Struct struct = (Struct) resultSet.getObject(s);
        Object[] attrs = struct.getAttributes();
        int srid = (Integer) attrs[0];
        Blob blob = (Blob) attrs[1];
        int type = (Integer) attrs[2];
        WKBReader reader = new WKBReader();
        Geometry geometry = reader.read(blob.getBytes(1, (int) blob.length()));
        geometry.setSRID(srid);
        return geometry;
    }

    @SneakyThrows
    @Override
    public Geometry getNullableResult(ResultSet resultSet, int i) throws SQLException {
        Struct struct = (Struct) resultSet.getObject(i);
        Object[] attrs = struct.getAttributes();
        int srid = (Integer) attrs[0];
        Blob blob = (Blob) attrs[1];
        int type = (Integer) attrs[2];
        WKBReader reader = new WKBReader();
        Geometry geometry = reader.read(blob.getBytes(1, (int) blob.length()));
        geometry.setSRID(srid);
        return geometry;
    }

    @Override
    public Geometry getNullableResult(CallableStatement callableStatement, int i) throws SQLException {
        return null;
    }
}
